Rinnai Recess Box - Metal

Rinnai



Rinnai Recess Box - Metal

The Rinnai Metal Recess Box enables an external continuous flow gas water heater to be recessed (either fully or semi recessed) into an external wall, behind a door and out of sight.


Construction


Folded galvanised steel, powder coated white. The recess box is supplied in white and can be easily customised to complement the house exterior by the owner or installer.
It is designed for new build installations as installation needs to commence during the framing stage, before internal linings, claddings or building wrap is applied.


Suitable for

New construction or major renovation. Installation needs to commence during the framing stage, before internal linings, claddings or building wrap are applied.

R1405 recess box, suitable for the following Rinnai INFINITY external gas continuous flow water heaters:• A16-A26 (current range)• VT16-VT26 (discontinued)• XR16-XR26 (discontinued)• V16-V24 (discontinued)

R1407 recess box, suitable for the following Rinnai INFINITY external gas continuous flow water heaters:• EF26 (current model)• HD200 (current model)• HD250 (current model)• EF24 (discontinued)• XR32 (discontinued)

A Rinnai INFINITY unit inside a recess box operates at a slightly louder level than a Rinnai INFINITY installed on an outside wall. Please bear this in mind when positioning near a bedroom as the operating noise could affect some people.

Building code compliance

Local authorities may have their own additional requirements regarding this type of installation. If in doubt over compliance with building codes, it is advisable they are consulted prior to installation.
The recess box installation can be compared to the detail required to install a meter box.


Rinnai Recess Box - Metal from  $553.00

SKU: R1407 TAG: CONTINUOUS
