Rinnai Bathroom Deluxe Controller
RINNAI
he Rinnai Bathroom Deluxe Controller works in conjunction with the Rinnai Kitchen Deluxe Controller
Digital controllers allow you to select the exact temperature of the hot water at the tap within the controller temperature range. This has a number of benefits:
- Safety: If you have young children, the hot water can be pre-set to a child-safe level for the period while you are filling the bath—a safety interlock feature prevents the water temperature from being adjusted from another controller while the bathroom controller is operating and hot water is flowing.
- Ability to transfer control back to the kitchen controller at the press of a button.
- No need to mix hot and cold water, this reduces the effect of temperature spiking when another tap in the building is turned on
- You use your Rinnai INFINITY continuous flow gas hot water unit more efficiently as less gas is required to heat water to 40 °C (typical shower temperature) than at 55 °C (default temperature without controllers)
- Allows diagnosis of problems (such as gas supply disruption) when the appliance is serviced by displaying 'error' codes, which the service person can utilise.
Suitable for
Domestic installations with a Rinnai INFINITY continuous flow gas hot water heater installed, refer compatible water heater models below.
Each remote controller can be individually programmed, however the water heater can only deliver one set temperature at any time.
Rinnai water controllers cannot be used with Rinnai INFINITY units connected to solar systems, when a Rinnai iHeat is installed, or in a ring main system using N-Series models.
Positioning
Deluxe controllers are water resistant, however, durability is improved when positioned outside the shower recess. All deluxe water controllers must be installed at least 400 mm above the highest part of a sink, basin, or bath.
Compatible with the following Rinnai water heater models
• Rinnai INFINITY N-Series• Rinnai INFINITY A-Series• Rinnai INFINITY EF26• Rinnai INFINITY HD range• Rinnai INFINITY EF range*• Rinnai INFINITY VT range*• Rinnai INFINITY XR range*
