Dab Shallow Well Pumps

DAB Shallow Well Pumps - Heavy-Duty Self-Priming Cast Iron Jet Pumps

Engineered to withstand the toughest Kiwi conditions, the DAB Shallow Well Jet Pump series delivers outstanding water pressure performance for New Zealand homes, lifestyle blocks, and agricultural applications. Whether you are pumping water from rainwater tanks, local bores, rivers, or dams, these self-priming multistage jet-assisted pumps offer trade-quality reliability and exceptional suction capacity—even when air bubbles are present in the water line.

Designed for versatile domestic, gardening, and small-scale irrigation setups, these heavy-duty cast iron pumps ensure a consistent, high-pressure water supply. Certified to meet strict AS/NZS 4020 standards, they are fully approved for safe, clean drinking water delivery, making them an ideal choice for rural household water systems.

Why Choose DAB Shallow Well Pumps for Your Project?

• Trade-Quality Durability: Built with a rugged cast iron pump body and motor support to resist wear and tear in demanding NZ environments.
• AS/NZS 4020 Drinking Water Approved: Certified safe for supplying drinking water to your home or batch.
• Superior Suction Lift: Self-priming design with a built-in Venturi tube system ensures excellent suction capability and fast priming, even with air-heavy water sources.
• Advanced Thermal Protection: Single-phase models feature built-in thermal and current overload protection alongside a permanently split capacitor to prevent motor burnout.
• Premium Internal Components: Equipped with a technopolymer impeller, diffuser, Venturi tube, and sand guard, reinforced with stainless steel adjustment rings and a high-performance carbon/ceramic mechanical seal.

DAB Shallow Well Pump Model Specifications

DAB-151M Surface-Mounted Cast Iron Jet Pump
Perfect for medium-sized residential water supply, garden irrigation, and wash-down setups.
• Power Output: 1.1kW (1.5hp), 240V
• Maximum Flow Rate: 75 Litres per minute (75L/min)
• Maximum Head Height: 61 meters (61m)
• Inlet/Outlet Port Sizes: 1 1/4" BSPF Inlet, 1" BSPF Outlet
• Standard Retail Price: $1259.25 (Please contact us to confirm latest pricing or trade discounts)

DAB-251M Surface-Mounted Cast Iron Jet Pump
A high-capacity powerhouse designed for larger lifestyle blocks, farm agricultural watering, and high-demand household pressure boosting.
• Power Output: 1.85kW (2.5hp), 240V
• Maximum Flow Rate: 120 Litres per minute (120L/min)
• Maximum Head Height: 62 meters (62m)
• Inlet/Outlet Port Sizes: 1 1/4" BSPF Inlet, 1" BSPF Outlet

Get the Right Pump Solution with Pratts

Need assistance choosing the correct pump size for your property, or require professional installation? The expert team at Pratts is here to help. We supply plumbing and water filtration solutions to trade professionals and homeowners across New Zealand. Contact us today for up-to-date pricing, trade accounts, or to request a custom installation quote from our registered plumbing specialists.
