Dab Esybox Water Pressure System

DAB

Upgrade your property's water supply with the Dab Esybox Water Pressure System (DAB-ESYBOX), the absolute gold standard in variable speed pressure pumps designed for New Zealand homes and light commercial applications. Whether you are dealing with weak shower pressure, upgrading a rural rainwater tank setup, or installing a high-end system for a new build, this intelligent, trade-quality water booster offers unparalleled performance, energy efficiency, and whisper-quiet operation.

Why the DAB Esybox is the Ultimate Water Pressure Solution for NZ Properties

Standard water pumps run at a single high speed, wasting energy and causing annoying pressure fluctuations in the shower. The DAB Esybox features a state-of-the-art variable speed inverter. This means the pump automatically adjusts its speed to match your water demand, delivering constant, perfectly balanced pressure across up to 12 taps simultaneously. Tested and certified to meet strict NZ standards, this system is AS/NZS4020 approved for safe drinking water, making it ideal for direct connection to mains or rainwater systems.

The E.SYBOX is a revolutionary and innovative all-in-one pump solution comprising of:

A self-priming multistage pump
Electronics for control and management
Pressure and flow sensors
High-resolution LCD display
2 Litre integrated expansion vessel

Key Features & Performance Benefits:

Whisper-Quiet Operation: Operating at just 45 dB in standard use--quieter than a normal conversation--this water pump is perfect for under-house or utility room installations without disturbing the household.
Energy Efficient & Cost Effective: The integrated variable speed drive (VSD) saves up to 30% of energy compared to traditional fixed-speed pumps.
Space-Saving All-in-One Design: Combines a self-priming multistage pump, water-cooled motor, expansion vessel, electronic sensors, and display into a compact unit that saves 30% of space in comparison with traditional systems.
Versatile Installation: It can be installed in a vertical or horizontal position, in a ventilated room or in a recess to fit your specific layout.
Smart Protection Systems: Built-in dry run protection stops pump damage if no water is present. Intelligent anti-freeze protection prevents the formation of ice inside the unit, while over/under voltage and over current protections keep the electrical components safe.
Wireless Connectivity: Built-in wireless device facilitates the creation of pressure booster sets and seamless connection to other DAB devices.
Trade Quality Assurance: AS/NZS4020 Drinking Water Approved, backed by a 2-Year Parts & Labour Warranty.

Technical Specifications:

Product Type: Variable Speed Pressure System
Suitable For: Clean Water (AS/NZS4020 Approved for Drinking Water)
Flow Rate (Max): 120 L/min (Flow Range Category: 100 - 199 L/min)
Max Head: 61m (Head Range Category: 60 - 99 m)
Pressure Rating: 6.1 Bar / 618 kPa
Motor Power: 1.55 kW (1550 Watts / 2.1 Hp)
Voltage: 240 V
Port Size: 1" BSPF inlet & 1" BSPF outlet
Self-Priming Depth: Up to 8 metres
Capacity: Rated for up to 12 Taps

Compatible Accessories Available at Pratts:

Tailor your system to your exact project requirements with these compatible DAB add-ons:

DAB-ESYDOCK: Pump docking station single for quick plumbing connections.
DAB-ESYLINK KIT: Wireless connection kit to link multiple Esybox systems.
DAB-ESYTWIN: Twin docking station for heavy-duty commercial or dual-pump setups.
DAB-ESYWALL: Dedicated wall-mount bracket to save premium floor space.

Get Expert Advice and Local NZ Support from Pratts

Ready to upgrade your water pressure or sourcing for a professional trade installation? Pratts is your trusted Kiwi specialist for plumbing, heating, and water pump systems. Contact us today to get the latest pricing, secure your Dab Esybox, or request a professional installation quote from our expert local trade team.
