DAB Self Priming Multistage Pump
DAB - SELF PRIMING STAINLESS STEEL HORIZONTAL MULTISTAGE PUMPS WITH ELECTRONIC PRESS CONTROL
Multistage horizontal centrifugal pump, featuring extremely silent running suitable for domestic use for water supply and pressurisation, irrigation of gardens and vegetable gardens, and moving water in general.
Ideal for long suctions and large homes. Suitable for high density urban applications.
• Stainless steel pump body.
• Motor support in die-cast aluminium, seal holder in AISI 304 steel.
• Mechanical seal in carbon/ceramic.
• Rotor shaft in AISI 304 steel. Rotors, diffuser bodies and diffusers in technopolymer.
• Adjustment rings in stainless steel.
• Protection level of motor: IP 44
• Protection level of terminal board: IP 55
• Insulation class: F
• Operating range: from 10 to 120 l/min. with a head of up to 72 m.
• Pumped liquid characteristics: clean, free from solid or abrasive substances, not viscous, not aggressive, not crystallised, chemically neutral and close to the characteristics of water.
• Liquid temperature range:
• from 0°C to +35°C C for domestic use (EN 60335-2-41)
• from 0°C to +40°C for other uses.
• Maximum ambient temperature: +40°C
• Maximum operating pressure: 8 bar (800 kPa)
• Euroinox: self-priming.
2 year DAB Warranty
a pressure tank is recommended for use with a Press Control. PRESSURE TANKS sold separately
Available in 4 models:
0.49kW, 0.67hp, 240V, max hd 46m, max flow 55lpm, Ports 1" BSPF in, 1" BSPM out
1.0kW, 1.36hp, 240V, max hd 72m, max flow 80lpm, Ports 1" BSPF in, 1" BSPM out
0.80kW, 1.1hp, 240V, max hd 57.7m, max flow 80lpm, Ports 1" BSPF in, 1" BSPM out
1.0kW, 1.36hp, 240V, max hd 59m, max flow 120lpm, Ports 1" BSPF in, 1" BSPM out
