Davey HM Series Horizontal Multistage Pumps

DAVEY



Davey HM series Horizontal Multistage Pumps

Horizontal multistage centrifugal pump with all hydraulic parts in stainless steel, for corrosion resistance.
• Suitable for high water temperatures up to 105°C.
• Easily convertible to an automatic pressure system by adding a Davey Torrium® or pressure switch.

APPLICATIONS:

Specific applications include:
• Water supply, boosting and transfer
• Irrigation and turf watering
• Wash down
• Emptying/filling reservoirs or tanks
• Water treatment (demineralisation, filtering etc)
• Commercial washing equipment

WHY CHOOSE THE Davey HM Series Horizontal Multistage Pump?

Horizontal multistage centrifugal pump with all hydraulic parts in stainless steel:
• Suitable for high water temperatures
• Corrosion and wear resistant

Axial suction and vertical discharge:
• Compact design
• Easy to install

Stainless steel impellers with high efficiency impeller profile and thick self-centring impeller neck rings for:
• High efficiency
• Reduced power consumption
• Low noise output

Air purging valve and stage porting:
• Easier priming
• Less susceptible to air leaks
• Improved dependability

Impellers mounted directly on extended shaft:
• Maximise performance per stage
• High efficiency
• Long motor and pump life
• Increased wear resistance

Pump casing assembly attached to motor bracket at 8 points with o-ring seal:
• Complete stainless casing
• Better sealing
• Longer service life

Davey built, totally enclosed fan cooled (TEFC) electric motor:
• Single-phase motors have built in thermal overload protection with automatic reset and 1.8m long power lead and Australian 3 pin plug
• Sealed and greased for life motor bearings
• Over sized drive bearing
• Longer life
• Easy service
• Economical & quiet running

Automatic control options:
Davey Torrium standard pressure switch and gauge multiple pump system:
• Versatile system design
• Simple automatic control
• Suitable for many applications

Available in models:

HM60-06 | kW(P2) - 0.58 | Inlet - 1 ¼" | Outlet - 1" -
HM60-08 | kW(P2) - 0.72 | Inlet - 1 ¼" | Outlet - 1" -
HM60-10 | kW(P2) - 0.94 | Inlet - 1 ¼" | Outlet - 1" -

HM90-08 | kW(P2) - 0.78 | Inlet - 1 ¼" | Outlet - 1" -
HM90-11 | kW(P2) - 1.05 | Inlet - 1 ¼" | Outlet - 1" -
HM90-13 | kW(P2) - 1.40 | Inlet - 1 ¼" | Outlet - 1" -

HM160-15 | kW(P2) - 1.50 | Inlet - 1 ½ " | Outlet - 1 ¼" -
HM160-19 | kW(P2) - 1.80 | Inlet - 1 ½ " | Outlet - 1 ¼" -

HM270-19 | kW(P2) - 1.90 | Inlet - 2" | Outlet - 1 ½" -
HM270-25 | kW(P2) - 2.5 | Inlet - 2" | Outlet - 1 ½" -

THREE PHASE:
HM160-15/3 | kW(P2) - 1.5 | Inlet - 1 ½ "" | Outlet - 1 ¼" -
HM160-19/3 | kW(P2) - 1.8 | Inlet - 1 ½ "" | Outlet - 1 ¼" -

HM270-19/3 | kW(P2) - 1.9 | Inlet - 2" | Outlet - 1 ½" -
HM270-25/3 | kW(P2) - 2.5 | Inlet - 2" | Outlet - 1 ½" -


Please contact us for latest pricing
